Wired Vehicle Tracking Device
Product specifications: 86mm × 37mm × 15mm
Product Overview: The X1-4GC GPRS GPS in car intelligent terminal is a 4G intelligent locator with a compact size, powerful functions, and built-in high-precision gyroscope. It can accurately sense the dynamic situation of the vehicle, and the terminal runs stably. It can be applied to asset management such as trucks, automobiles, engineering machinery equipment, two wheeled electric vehicles, as well as different industries suc
|
Project |
Technical Parameter |
|
Working voltage |
9VDC~90VDC |
|
Working current |
30mA~50mA(DC12V) |
|
Positioning module |
Support GPS+BD dual system positioning |
|
Communication method |
TCP |
|
Communication network |
GPRSGPS+BD |
|
Locate mode |
<10m |
|
Position error |
Less than 4g |
|
Acceleration limit |
Synchronize GPS time |
|
Time accuracy |
Precision vibration sensor |
|
Sensor |
-20℃~70℃ |
|
operation temperature |
-30℃~85℃ |
|
Storage temperature |
86mm×37mm×15mm |
|
Terminal size |
9VDC~90VDC |
|
Function |
Function Details |
Function Description |
|
Positioning
|
Scheduled upload |
The terminal returns location information such as latitude and longitude to the server at set time intervals |
|
Base station positioning |
Determine the location of mobile devices through mobile communication base stations |
|
|
Vehicle status detection
|
Ignition/Shutdown |
Each uploaded data contains ACC data |
|
Power outage alarm |
After the host detects that the vehicle voltage is below 20V, it provides feedback to the platform with a power failure alarm |
|
|
Low voltage alarm |
After the host detects that the vehicle voltage is below 20V, it provides a low voltage alarm feedback to the platform |
|
|
Parking alarm |
When the vehicle detected by the terminal stops at a prohibited parking location and the duration is greater than 15 minutes, a parking alarm will be provided to the platform as feedback |
|
|
OVERSPEED |
When the vehicle speed detected by GPS is greater than the maximum speed limit set by the platform and the duration is greater than 3 seconds, it will give feedback to the platform for over speed alarm |
|
|
Other
|
Alarm for entering and exiting the area |
When the vehicle detected by the terminal approaches the special area divided by the platform, it will provide the platform with feedback on the entry and exit area alarm function when entering and exiting |
|
Blind spot supplementary transmission |
When encountering poor signal during terminal positioning, store positioning data and upload it normally when there is a signal |
|
|
Mileage statistics |
The terminal records and calculates the driving mileage, which can be uploaded to the platform for reference |
|
|
SMS inquiry address |
Authorized mobile phones send requests to search for vehicles to the platform. Based on the location information uploaded by the terminal, the platform captures and provides feedback to the mobile phone via SMS, supporting both Chinese and English SMS |
|
|
SMS alarm |
When the terminal detects that the vehicle is in an abnormal state such as speeding, entering or leaving the area, illegal starting, or power failure, the platform sends an alarm notification to the relevant mobile phones in the form of SMS while receiving the alarm information |
|
|
SMS setting with defense and disarming functions |
After setting the security function in SMS, if the car vibrates for 10 seconds, a vibration alarm will be sent to the platform and mobile phone |
|
|
Remote Upgrade |
Support remote upgrade for easy maintenance |
